The following table lists INPUTS and OUTPUTS for the VIP5
Note 2 : for active sensors, the maximum current available is 100mA in total on +Ve.
When using clean contacts, the VIP5 will use 12 or 24V to monitor the contact.
*Note 1: If using NAMUR wire sensors, a 1.5kΩ to 2.5kΩ resistor should be installed between Signal and GND (see
paragraph 6.1 for wiring diagram)
Location
TYPE
PINOUT LABEL
DESCRIPTION
NOTES
Terminal
Number
M1
1
Output
Motor line 1 (+)
Pump/Solenoid Connection
max 10A @ 230V~
Power is supplied via
relay from pins 3 and 4
M1
2
Motor line 2 (-)
M1
3
Input
Power AC/DC input 1 (+)
Power connection for VIP5
12V/24V/110V~/230V~
Depending on Model
purchased.
M1
4
Power AC/DC input 2 (-)
M2
1
Output
Alarm contact NC
Remote alarm relay
Max 2A @ 30V ~
M2
2
Alarm contact COMMON
M2
3
Alarm contact NO
M2
4
Input
LL
Minimum Level Sensor
Open contact, or
PNP,NPN,NAMUR
(*see Note 1)
M2
5
GND
M2
6
Input
IN010
0-10V Volt analogical input
Not used
M2
7
Analog GND
M2
8
Input
IN 420
4-20 mA analogical input connection
point
Not isolated
M2
9
Analog GND
M2
10
Input
+Ve (see Note 2)
Input for external counting device.
PNP/NPN or clean contact.
Suspend input in CYCLE mode.
Clean contact,
PNP,NPN,NAMUR
(*see Note 1)
M2
11
PULSE
M2
12
GND
M2
13
Input
+Ve (see Note 2)
First Sensor Input for monitoring
system.
Eg. Pressure switch for injectors or
Cycle switch for progressive system
Suspend input in TIMER mode.
Clean contact,
PNP,NPN,NAMUR
(*see Note 1)
M2
14
P1
M2
15
GND
M2
16
Input
+Ve (see Note 2)
Second Input for monitoring system.
Eg second pressure switch on a dual
Line System
Clean contact,
PNP,NPN,NAMUR
(*see Note 1)
M2
17
P2
M2
18
GND
