9.3 PARAMETERS AND VALUES
The following table explains the parameters and possible values of the VIP5 selecting basic or extended menu.
PARAMETER
NAME
DEFAULT
VALUE
DESCRIPTION
VALUES/ RANGE
APPLICABILITY
MODE
CYCLE
SELECTS THE OPERATING MODE:
Flow monitoring mode
FLOW
FLOW
Lubrication Cycle completed when the cycle
sensor confirms correct lubrication
CYCLE
CYCLE
Both Standby and Lubrication Phase
determined by external signal.
PULSE
PULSE
TYPE
(Basic)
SEP
SELECTS THE CYCLE MONITORING:
X
X
Timer only
TIMER
TIMER/NO CONTROL
Pressure switch
PS
Progressive Cycle switch
SEP
PS
Dual Line Pressure switches
DUAL
DUAL
SEP
INVE.Wait
.null.
Waiting time for inversion command and
pump
1s - 1h
X
X
X
PAUSE BY
TIMER
Determines Standby Phase Timing
Time based Standby
Time
Whichever of above 2 events occurs first.
Counter
Time &
A set number of external PULSE signals
Counter
By PULSE signals. However, if PAUSE TIM. is
reached, an alarm will be given
TOUT & Counter
PAUSE TIM.
(Basic)
6m 00s
Standby Timer setting. Null means the
standby phase will be skipped
Null
– 99h 00m
X
X
X
X
X
CYCLE TOUT
30 sec
Timeout counter determines how long to wait
for cycle completion before a timeout alarm is
generated.
1s-1h
X
X
X
X
X
X
LUBE TIME
(Basic)
30 sec
In timer Mode, how long the pump will run.
0s – 99h
X
X
LUBE CYCLES
1
Number of Lubrication Cycles to complete a
Lubrication Phase
1 – 250
X
X
X
X
X
START IN
Resume
Determines state at power on:
Start in Lubrication Phase
Resume from power down state
Lube
Resume
X
X
X
X
X
X
PRELUBE
0
Number of Prelube Cycles
0 - 250
X
X
X
X
X
ALARM
Standard
How REMOTE ALARM is managed
X
X
X
X
X
X
X
Relay is powered off during alarm
Standard
Relay is powered On during alarm
Inverted
A Pulse Coded Alarm signal is given ( for
details see section 10.3)
Coded
STOP
On all
Determines what Alarm conditions should
stop the VIP5 Lubrication cycles.
Never stop the lubrication cycle
On None
All alarm conditions
On All
All but min Level stops the Vip5
All but min Level
Only minimum level alarm stops the VIP5
Min level only
All but Maximum Level
All but Max level
PUMP
(Basic)
Continuous
Pump output can be constant signal, pulsed
signal or synchronized with control signal
(see next 3 parameters)
Continuous
Pulsed
X
X
X
X
X
X
Synchronized
X
PUMP TON
3.0
Sets the ON value of the pump pulse.
0.1-25.0s
X
X
X
X
X
X
PUMP TOFF
2.0
Sets the OFF value of the pump pulse.
0.1-25.0s
X
X
X
X
X
X
WAIT TIME
10s
Time between two Lubrication Cycles within
the Lubrication Phase
Null - 2 min
X
X
X
X
X
BOOST CYCLES
1
In a SEP mode, If P2 input is closed the LUBE
CYCLES values is increased by this value
contained in this setting
1 - 250
X
X
