English–PACE Indicators Instruction Manual | 27
Instrument Status
3.8 Instrument Status
The control setup menu provides access to the status of the instrument:
Instrument
Software installed
Hardware build
Instrument Status
IEEE488*
Instrument Main Code
Instrument OS Build
Instrument Boot ROM
Analogue O/P Main Code
Analogue O/P Boot ROM
VFC Main Code
VFC Boot ROM
Additions to the
standard instrument
Pressing the escape key
stores settings and returns to
global set-up.
History
Calibration
Zero
Software
Hardware
Message
Communications
RS232*
* current settings, see 6.7
Current set-up
Support
Contact details
Ethernet (optional)
USB
Ethernet
More
