36 | PACE Indicators Instruction Manual–English
Chapter 6. Reference
6.3.3 Task
Selecting Task enables a set of pre-determined functions and software enabled optional
functions.
6.3.4 Units
Select the new units from the list of pressure measurement units. Special units can also be
defined. Refer to
Section 6.6.6, “User Defined Units,” on page 50.
6.3.5 Global Setup
Refer to Section 6.5, “Global Setup,” on page 37.
6.3.6 Setup Zero
Zero from top level screen (main range only).
If other ranges are fitted these can be zeroed by selecting the displayed reading.
6.3.7 Barometric Reference Option
The barometric reference option measures the barometric pressure at the reference port.
Depending on the sensors fitted, it also permits the indicator to operate in either pseudo-gauge
or pseudo-absolute mode by the addition of barometric pressure.
6.4 Status
The display shows the following:
a. Instrument status
• Model
• Serial number
• MAC address sensor(s)
• Range
• Last calibration date
*
.
• Software build - read only data.
b. Hardware build - read only data.
c. History - read only data
• Calibration
• Zero
• Software
• Hardware
• Message
• Ethernet connection
d. Communications, IEEE 488 and RS-232 are fitted as standard. Additional communication
types are options - USB and Ethernet.
e. Current setup - read only data.
f. Support
• List contact information for support and advice.
* The instrument date and time must have been set correctly.
