Appendix 3: Template Programming Tables
DLS/Installer Lead In/Out Group DLS/Installer Lead In/Out Programming
DLS/Installer Disabled
[308][312] - Bit 1 Installer Lead In - Off
[308][312] - Bit 2 Installer Lead Out - Off
[308][312] - Bit 3 DLS Lead In - Off
[308][312] - Bit 4 DLS Lead Out - Off
[308][312] - Bit 5 SA Lead In - Off
[308][312] - Bit 6 SA Lead Out - Off
Digit 5 DLS Connection Options
Option Programming Section DLS Connection/Call Back Setting
1
[401] Option 1 OFF
Option 3 OFF
Option 4 OFF
[406] 000
Double CallDisabled
Call Back Disabled
User Initiated CallUp Disabled
Number of Rings to Answer On Disabled
2
[401] Option 1 ON
Option 3 OFF
Option 4 OFF
[406] 008
Double CallEnabled
Call Back Disabled
User Initiated CallUp Disabled
Number of Rings to Answer On is 8
3
[401] Option 1 ON
Option 3 ON
Option 4 OFF
[406] 008
Double CallEnabled
Call Back Enabled
User Initiated CallUp Disabled
Number of Rings to Answer On is 8
4
[401] Option 1 ON
Option 3 OFF
Option 4 ON
[406] 008
Double CallEnabled
Call Back Disabled
User Initiated CallUp Enabled
Number of Rings to Answer On is 8
After entering a valid 5-digit template programming code, the system prompts for the following data in the sequence listed:
1. Central Station Telephone Number
i. Program the required central station phone number. Press [#] to complete your entry.
ii. This phone number is entered into programming section [301][001].
2. Central Station System Account Code (4 or 6-digit code)
i. Program the system account code. All digits must be entered in order to complete your entry.
ii. This account code is entered into programming section [310][000].
3. Partition 1 Account Code (4 digit code)
i. Program the partition 1 account code. All digits must be entered in order to complete your entry.
ii. This account code is entered into programming section [310][001]
4. DLS Access Code (6-digit code)
i. Program the required DLS access code. All 6 digits must be entered in order to complete your entry.
ii. This access code is entered into programming section [403].
5. Entry Delay 1 and Exit Delay
