PC3000 Version 7.51
[25] New Master Code (Access Code Number 1) Page 19
Default
1 2 3 4 Enter 4 digits from 0 to 9.
Do not enter [Q] or [#].
[26] Downloading Access Code Page 19
Default
3 0 3 0 Enter 4 digits from 0 to 9.
Do not enter [Q] or [#].
[27] Communicator Format Options Page 19
Default
1 1st Telephone Number
1
2nd Telephone Number
Enter one HEX digit from [0] to [D] from list for each phone number from list:
[0] Silent Knight/Ademco slow, 10 BPS (1400 Hz handshake) 3/1 and 4/1, 4/2 non extended format
[1] Sescoa, Franklin, DCI, Vertex, 20 BPS (2300 Hz handshake) 3/1 and 4/1, 4/2 non extended format
[2] Silent Knight fast, 20 BPS (1400 Hz handshake) 3/1 and 4/1, 4/2 non extended format
[3] Radionics, (2300/1400 Hz* handshake) 3/1 and 4/2 non extended format
[4] Radionics, (2300/1400 Hz* handshake) 3/1 and 4/2 non extended with parity format
[5] Sescoa super speed
[6] Not used
[7] Not used
[8] Silent Knight/Ademco slow, 10 BPS (1400 Hz handshake) 3/1 extended format
[9] Sescoa, Franklin, DCI, Vertex, 20 BPS (2300 Hz handshake) 3/1 extended format
[A] Silent Knight fast, 20 BPS (1400 Hz handshake) 3/1 extended format
[B] Radionics, (2300/1400 Hz* handshake) 3/1 extended format
[C] Radionics, (2300/1400 Hz* handshake) 3/1 extended with parity format
[D] Sescoa super speed (with identified openings/closings)
*See section [19] for Radionics Handshake Option
[28] Programmable Input and Output Options Page 20
Note: If a printer is attached to the panel, both [0] for the 1st digit and [C] for the 2nd digit must be entered.
Default
2 Auxiliary Input Zone Enter 0, 1, 2 or 3 for options below 0,1, 2 and 3 are the
(Normally open, momentary [0] Printer attached only valid entries
closure to “Aux +”) [1] Silent 24 hour input
[2] Audible 24 hour input
[3] Momentary key arming
2 Programmable Output Enter 1 to F for options below 1 through F are
(A 50 mA switch to ground.) [1] Ground start pulse the only valid entries
Note: A relay must be used to [2] Utility output no access code
obtain more current. [3] Utility output any access code
[4] Utility output Group A access code
[5] Utility output Group B access code
[6] Keypad buzzer follow mode
[7] System status (arm/disarm) output
If only using first telephone number, enter
same digit into 2nd phone number.
