30
PC3000 Version 7.51
[8] Strobe output (latched alarm output)
[9] Failure to communicate output
[A] TLM and alarm
[B] Courtesy pulse
[C] Printer attached
[D] 2nd line slave
[E] Kissoff output
[F] Remote operation
(DLS-1 version 4.0 or later)
Note: Section [29]...[33] are used for split arming or split reporting only.
[29] Zone Group A Assignment Page 21
Default
On Zone Light 1
On
Zone Light 2
On
Zone Light 3
On
Zone Light 4
On
Zone Light 5
On
Zone Light 6
On
Zone Light 7
On
Zone Light 8
[30] Zone Group B Assignment Page 21
Default
On Zone Light 1
On
Zone Light 2
On
Zone Light 3
On
Zone Light 4
On
Zone Light 5
On
Zone Light 6
On
Zone Light 7
On
Zone Light 8
Note:
If zone light is on that zone is assigned to
Group A.
Zones 9 to 16 are permanently assigned to Group A.
Note:
If zone light is on that zone is assigned to
Group B.
If zone light is on in both sections, the zone is
common to both sides and will only be armed if both
sides are armed.
