Response
Code
Description of Response Code Corresponding Action
E0
Reserved
E1
E2
E3
E4
E5 Remote firmware update disabled
Enable remote firmware update in the communicator in order to
perform remote system firmware update.
Local Status Update States
FE Firmware file empty
No action required. Communicator currently does not have any
firmware files.
FD Firmware download in progress
No action required. Communicator is currently downloading
firmware.
The table above displaysthe firmware update indicator codes and meaning of each code. The updates can be made from com-
municator. Communicator can update firmware of the panel and also of communicator itself. This section does not provide spe-
cific details such as if the image is still stored or erased due to the cancellation code.
[984] Communicator Status
The communicator status sections provide the installer with the status of the communicator’s functionality, operational read-
iness, and failures.
The communicator status is displayed as a 6-digit hexadecimal code. The code ranges between 00000F and 2220CF, though
not all numbers in this range are assigned. Each of the 6 digitsrepresents a status or trouble indicator as below:
1. Digits 1 & 2: Reserved.
2. Digit 3: Network Indicator, indicates the operational status of the network.
3. Digits 4 & 5: Trouble Indicator displays the type of issue on the communicator or modules associated with and connected
to communicator. See Table 6 on page 12 for a listing of possible values.
4. Digit 6: Reserved, displays as ‘F’ or ‘-’.
For example, a value of 11002F means:
11- Reserved.
0 - No network issues
02 - Panel supervision trouble with the communicator
The status code for the radio signal strength, its typical troubles,possible causes and troubleshooting instructions is displayed
in the table below.
Table 12: Network Indicator - Digit 3
Network Indicator Value Means
OFF No network trouble
ON
Ethernet cable disconnected
Ethernet DHCP failed
Flashing
Incoming transmission
Outgoing transmission
Incoming transmission
[987] Language Version
This section will display the current language version of the communicator.
[988] DNS 1 IP Address
This section will display the IP address of DNS Server 1. This is useful when the unit is configured for DHCP and the IP address
was assigned to the device by the DHCP server is needed. This value is programmed in Section [007] or assigned by DHCP.
[989] DNS 2 IP Address
This section will display the IP address of DNS Server 2. This is useful when the unit is configured for DHCP and the IP address
that was assigned to the device by the DHCP server is needed. This value is programmed in section [008] or assigned by
DHCP.
[990] Boot Loader Version
This section will display the current boot loader version of the communicator.
20
