DSC TL2803GR - Receiver Diagnostic Testing; System Information (Read Only)

38
HSPA(3G) Alarm Communicator Installation Manual
[663] Interactive Toggle Option
[1] Interactive Over Serial Toggle Default (ON)
ON: Interactive over serial enabled.
OFF: Interactive over serial disabled.
[2] Reserved
[3] Reserved
[4] Reserved
[5] Interactive Protocol ITV2 Default (ON)
ON: Interactive protocol ITV2 enabled.
OFF: Interactive protocol ITV2 disabled.
[6] Reserved
[7] Reserved
[8] Reserved
NOTE: Option 1 and Option 5 must both be ON for the interactive feature to operate.
Receiver Diagnostic Testing
[901] Diagnostic Test Transmission
[1] Ethernet 1 (OFF).
[2] Ethernet 2 (OFF).
[3] Cellular 1 (OFF).
[4] Cellular 2 (OFF).
[5],[6],[7],[8] Reserved(OFF).
This section may be used by the installer to force the communicator to send an immediate test
transmission to specific receivers, to verify that the communications paths are available.
Diagnostic test transmission failure will indicate as an FTC trouble (yellow LED = 9
flashes). If an FTC error occurs when testing all receivers, select only one receiver and
repeat test to isolate the receiver that is not communicating.
NOTE: Sending a test transmission to a receiver that is not programmed generates an FTC trou-
ble.
System Information (Read Only)
NOTE: Sections [983] - [998] are provided for information (read only). Values in these sections
cannot be modified by the installer.
[617] Help (Help)
[618] Pay As You Go Balance
Request
(Balance Request)
[619] Keypad Message (Keypad Message) [621] Function Successful (Successful)
[622] Function Failure (Unsuccessful) [623] Invalid Command (Invalid Command)
[624] System Stay Armed (Stay Armed) [625] System Away Armed (Away Armed)
[626] System Night Armed (Night Armed) [627] System Disarmed Ready (Disarmed Ready)
[628] System Disarmed, Not
Ready
(Disarmed Not Ready) [629] System In Alarm (is in Alarm)
[630] Trouble Label (Service is Required) [631] No Alarms in Memory (No Alarms in Memory)
[632] Pay As You Go Balance (Pay as you go balance:) [633] Pay As You Go Message (*123#)
[634] Response Code (Response Code)
Table 15: External Event Labels
Event [Section] Label Default Label Event [Section] Label Default Label
