HSPA(3G) Alarm Communicator Installation Manual
System Options
[001] Ethernet IP Address
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[002] Ethernet IP Subnet Mask
Default (255.255.255.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[003] Ethernet Gateway IP Address
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[004] Receiver Supervision Interval
Default (0087/135) Valid range: 0000 - FFFF.
|____|____|____|____|
[005] System Toggle Options
|____| [1] Ethernet Receiver 1 Supervised Default (OFF).
|____| [2] Cellular Receiver 1 Supervised Default (OFF).
|____| [3] Supervision Type Default (OFF).
|____| [4] Primary Communications Path.
Default (OFF) TL2803G(R); (ON) 3G2080(R).
|____| [5] Redundant Communications Default (OFF).
|____| [6] Remote Firmware Upgrade Default (ON).
|____| [7] Alternate Test Transmission Default (OFF).
|____| [8] Cellular Low Signal Trouble Default (OFF).
[006] System Toggle Options 2
|____| [1] Ethernet Receiver 1 Enabled Default (ON).
|____| [2] Ethernet Receiver 2 Enabled Default (ON).
|____| [4] Cellular Receiver 1 Enabled Default (ON).
|____| [5] Cellular Receiver 2 Enabled Default (ON).
|____| [7] DLS Over Cellular Default (ON).
[007] DNS Server IP 1
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[008] DNS Server IP 2
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[009] Language
Default (01); Program label language 01-29
|____|____|
Programming Options
[010] System Toggle Options 3
|____| [1] Reserved.
|____| [2] Visual Verification Default (OFF).
|____| [3] Reserved.
[011] Installer Code
Default (CAFE) Valid range: 0000 - FFFF.
|____|____|____|____|
[012] DLS Incoming Port
Default (0BF6/3062) Valid range: 0000 - FFFF.
|____|____|____|____|
[013] DLS Outgoing Port
Default (0BFA/3066) Valid range: 0000 - FFFF.
|____|____|____|____|
[015] DLS Call-Up IP
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
ETHERNET/CELLULAR PROGRAMMING WORKSHEETS
[997] IMEI Number
This section will display the unique 15-digit International Mobile Equipment Identity (IMEI) of
the radio. Format is: Reporting Body Identifier (2 digits), Allocation Number (4 digits); Final
Assembly Code (2 digits); Serial Number (6 digits); and a check digit.
[998] MAC Address
This section will display the unique12-digit, hexadecimal number assigned as the Media Access
Control (MAC) address of the device.
System Reset Defaults
[999] Software Default
Default (99);
The software default allows the installer to refresh the unit after changes and also return the com-
municator to the default state.
00: Default Module. All programming sections in the module revert to factory settings. This will erase
all existing programming of the unit.
11: Default Labels. Sets all programmable labels to the language selected in section [009].
55: Reset. The communicator is reset. This option is equivalent to power cycling the communicator.
