HSPA(3G) Alarm Communicator Installation Manual
[984] Communicator Status
The communicator status sections provide the installer with the status of the communicator’s func-
tionality, operational readiness, and failures.
The communicator status is displayed as a 6-digit hexadecimal code. The code ranges between
00000F and 2220CF, though not all numbers in this range are assigned. Each of the 6 digits rep-
resents a status or trouble indicator as below:
1. Digits 1 & 2: Signal strength indicators display the presence/strength of cellular radio.
2. Digit 3: Network Indicator, indicates the operational status of the network.
3. Digits 4 & 5: Trouble Indicator displays the type of issue on the communicator or modules associ-
ated with and connected to the communicator. See Table 8 on page 18 for a listing of possible val-
ues.
4. Digit 6: Reserved, displays as ‘F’ or ‘-’.
For example, a value of 11002F means:
11- Signal strength is excellent
0 - No network issues
02 - Panel supervision trouble with the communicator
The status code for the radio signal strength, its typical troubles, possible causes and troubleshoot-
ing instructions is displayed in the table below.
Table 17: Radio Signal Strength - Digits 1 and 2
Table 18: Network Indicator - Digit 3
[985] Radio Initialization Status
The radio initialization status provides installers with the status of radio communication. It is dis-
played as an 8-digit toggle option, with each digit indicating a task in the initialization process.
1. Radio power up
2. Reserved
3. Radio reset
4. Radio attached to network
5. Receiver 1 initialized
6. Receiver 2 initialized
7. Receiver 3 initialized
Signal
Strength
CSQ
Level
Signal
Indicator
1
Signal
Indicator
2
Signal
Level
[dBm]
Signal
Level
Status
Action Required
No Signal 0 0 0 -108.8 bad
Check all antenna connections.
Confirm cellular service is active in area.
Relocate panel or install external antenna.
1 Bar 1 - 4 0 2 -108 ~ -103 weak Relocate panel or install external antenna if
yellow trouble LED has:
5 flashes.
2 Bars 5 - 6 0 1 -102 ~ -99 weak
3 Bars 7 - 10 2 1 -98 ~ -91 strong
Location is OK. Cellular signal strength is
greater than CSQ 7.
4 Bars 11 - 13 2 1 -90 ~ -85 strong
5 Bars 14 + 1 1
-84 and
higher
excellent
Network indicator Value Means
OFF No network trouble
ON
Ethernet cable disconnected
Ethernet DHCP failed
Radio connection has been rest
Radio IP failed
Flashing
Incoming transmission
Outgoing transmission
Incoming transmission
