5.4.3 GENERATOR
Contains electrical values of the generator (alternator), measured or derived from the module’s
voltage and current inputs.
• Generator Voltage (ph-N)
• Generator Voltage (ph-ph)
• Generator Frequency
• Generator Current
• Generator Earth Current
• Generator Load %
• Generator Load (kW)
• Generator Load (kVA)
• Generator Power Factor
• Generator Power Factor Average
• Generator Load (kVAr)
• Generator Load (kWh, kVAh, kVArh)
• Generator Phase Sequence
• Generator Config (Nominals)
• Generator Active Config
5.4.4 BUS (DSE7410 ONLY)
• Bus Voltage (ph-N)
• Bus Voltage (ph-ph)
• Bus Frequency
5.4.5 MAINS (DSE7420 ONLY)
NOTE: Mains current and power measurement is is only available in DSE7420 V1.3 when
the CT location is selected to be the load.
• Mains Voltage (ph-N)
• Mains Voltage (ph-ph)
• Mains Frequency
• Mains Current
• Mains Load %
• Mains Load (kW)
• Mains Load (kVA)
• Mains Power Factor
• Mains Power Factor Average
• Mains Load (kVAr)
• Mains Load (kWh, kVAh, kVArh)
