There are corresponding interfaces for this function and provide 24v-35v flash light voltage. Connect the flash light
with DC 24v-28v,current ≤ 500mA(Fig.19). When use AC 230-240V power flash lights, please match an adapter,
and wiring as required (Fig.20 p.12). Upon opening or closing the light will flash as a safety function
This function ensures that the door can’t be opened unless the small pass door is closed.
The door panel won’t be damaged. Connect according to Fig.18 p.12
HOLIDAY LOCK OUT ON/OFF
Press and hold SET (K1) until the LED display setting number 4,
release SET (K1). It is now in holiday lock out program.
Press UP (K3), LED display 1, holiday lock out is now activated
or press DOWN (K4) , LED displays 0, holiday lock out is now
de-activated. Press SET (K1) to store your settings.
The GDO will allow one opening and closing. After closing, allow
2 seconds for lock out to activate
Note: When the GDO is in lock out mode, the DTS TX5 Octo is
the only transmitter that can be used to open the GDO. First
press button ‘3’ (Fig. A) followed by programmed button within 2
seconds
