SLICE User’s Manual July 2017
support.dtsweb.com 10 Version 1.0i
2.3.4. ACCEL SLICE
The ACCEL SLICE has Bridge SLICE electronics with the addition of a built-in 3-
axis accelerometer. The following specifications apply:
• Options from 25 to 500 g
• DC response
2.3.5. ARS PRO SLICE
The ARS SLICE has Bridge SLICE electronics with the addition of a built-in 3-axis
angular rate sensor. The following specifications apply:
• Uses DTS ARS PRO (see http://dtsweb.com/products/dtsars.php)
• Options from 300 to 8000 deg/sec
• DC response
2.3.6. Battery SLICE
The Battery SLICE is connected to the bottom of the Base+ SLICE. It is only
available in the SLICE NANO version. The Battery SLICE is only a back-up
battery in case main power is lost. Specifications:
• 2-cell LiPo design, with charging directly from Base+ SLICE
• Only 3.5 mm thick
Accel and ARS
SLICEs can be
positioned in any
order in a SLICE
MICRO Stack
ARS SLICE
ACCEL SLICE
