4.2. Supported Sensor Types
The Bridge SLICE supplies 5 VDC excitation up to 20 mA and supports many types of
accelerometers, load cells, pressure sensors and other sensor types. The following
general sensor types are supported:
• Full (4-wire) or half bridge (2- or 3-wire) resistive and piezo-resistive types
• Voltage input: Input range 0.1 to 4.9 V; larger range with voltage expander
circuit
• Conditioned sensors with 5 V excitation and 2.5 V centered signal output
• Common piezo-electric sensor types
If you have questions regarding what sensors are supported, please contact
support.dtsweb.com and provide the sensor manufacturer and model number if
available.
