DTS SLICE MICRO - Page 44

Recommended Grounding Architecture
Vehicle Body or Test Article
Sensor
SLICE
DAS Mounting Plate
Sensor Cable
Shield NOT
connected
here
Isolated metal
structure such
as a dummy
component
SLICE
Stack
Ground Cable
Earth
Ground Cable to “Earth”
© 2009-2010 DTS Principles of Dynamic Data Acquisition
Earth
