DTS SLICE MICRO - Page 52

Switch Closure
+EX
-EX
-SIG
+SIG
+ID
-ID
Shield
3
1
2
6
7
5
4
−EX
+ID
Æ Internal to SLICE Bridge
Electronic ID
Interface
Excitation
5-volts 20 mA
+EX
3K
3K
−ID
Half-Bridge Switch
Sensor Side Å
+SIG
−SIG
Amplifier
1K
2.5V
Example Sensor Settings
• Half-Bridge Mode
• Proportional to Excitation = No
• Sensitivity = 1.000 mV/EU will scale
data in mV at input. Switch closure
as shown gives 833 mV deflection.
1K
1K
