DTS XR2000 BEAM User Manual

ARC 1200
XR2000 BEAM
13- DISPLAY FUNCTIONS
RESET
ENABLED
MENU ENTER DOWN UP
Reset
Up-Down
Up-DownENTER
ENABLED = Reset via DMX enabled
(Default)
DISABLED = Reset via DMX disabled
NOW = Unit motors reset
ENTER
Menu
RESET
Reset via DMX ENABLED / DISABLED
and unit reset
BY DMX
CMY BLACKOUT
ON
MENU ENTER DOWN UP
CMY Blackout
Up-Down
Up-DownENTER
ON = Blackout enabled (Default)
OFF = Blackout disabled
ENTER
Menu
CMY BLACKOUT
CMY filters blades inserted at 100% if the dimmer
remain closed for more than 5 seconds.
By activating this function, it will be possible to
reduce substantially any visible light reflection
coming out from the front lens when dimmer is
closed.
SYSTEM INFO
LAMP LIFE:0000H STRIKE:001
UNIT LIFE: 0010H
8M R.20
PT R.19
MODEL: XR2000 BEAM
MENU ENTER DOWN UP
System info
Up-Down
Up-DownENTER
SYSTEM INFO
Lamp life time, lamp strikes, unit life
time, 8 motors card software
version, Pan&Tilt card software
version and unit model
ENTER
Menu
SYSTEM INFO
Lamp life time, lamp strikes, unit life time, 8
motors card software version, Pan&Tilt card
software version and unit model
Reserved
Up-Down
Up-DownENTER
Pan Lock = Lock the Pan to the
desired value
Tilt Lock = Lock the Tilt to the
desired value
Pan Free = Remove power to Pan
motor
Tilt Free = Remove power to Tilt
motor
System Reboot = Unit Reboot
without needing of turning OFF the
unit
ENTER
Menu
RESERVED
Pan lock-Tilt lock
Pan free-Tilt free
System Reboot
(Code = 100)
RESERVED
000
MENU ENTER DOWN UP
ENTER CODE
PAN LOCK
NO
MENU ENTER DOWN UP
FAN SPEED
5
MENU ENTER DOWN UP
Fan Speed
Up-Down
Up-DownENTER
Fan speed control
1-5 (Default = 5)
ENTER
Menu
FAN SPEED
Fan Speed control
GOBO ROTATION
OFF
MENU ENTER DOWN UP
Gobo Rotation
Up-Down
Up-DownENTER
ON
OFF = (Default)
ENTER
Menu
GOBO ROTATION
Gobo rotation control the Rotating speed of gobo
During gobo scrolling
16
