21 CHANNELS MODE (DEFAULT)
1 PAN msb 540°
2 PAN lsb
3 TILT msb 270°
4 TILT lsb
5 SPEED MOVEMENT
6 DIMMER
7 SHUTTER
8 COLOUR
9 COLOUR mode
10 CYAN
11 MAGENTA
12 YELLOW
13 SPEED CMY
14 MACRO CMY
15 GOBO
16 GOBO MODE
17 GOBO ROTATION/INDEX
18 GOBO INDEX FINE
19 GOBO SHAKE
20 FROST
21 RESET - LAMP
22- DMX PROTOCOL
DMX CHANNEL 1
Parameter: PAN msb
DMX CHANNEL 2
Parameter: PAN lsb
DMX CHANNEL 3
Parameter: TILT msb
DMX CHANNEL 4
Parameter: TILT lsb
DMX CHANNEL 5
Parameter: SPEED MOVEMENT
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
000 - 010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to
DMX signal ( fast to slow)
248-255
Silent Mode
ARC 1200
XR2000 BEAM
22
