DTS XR2000 BEAM User Manual

4- TECHNICAL FEATURES
Dimensions
5- ACCESSORIES
As standard
•1 x MSR Gold 700/2 Fastfit lamp
•1 x POWERCONN male cable connector (cod. 0520P014)
•1 x XLR 5 Pins male cable connector (cod. 0508B028)
•1 x XLR 5 Pins female cable connector (cod. 0508B027)
•5 x Metal Gobos
•2 x “C” Clamp GQUICK with “Fast Lock” connection 1/4 turn (max. load. 80Kg) (cod. 0521A014)
• User’s manual
Optional (on request)
• Double Professional Flight case; compartment for lamps and accessories, swivel wheels, cover with
hinges with-stay, dishes on cover for piling, 8 handles (2 each side) (cod. 0521C038)
• Raincover for XR2000 base (top) (cod. 03.MA009)
• Raincover for XR2000 base (bottom) (cod. 03.MA010)
• Embedding flange for XR2000 (visible display) (cod. 03.MA008)
• Embedding flange for XR2000 (no visible display) (cod. 03.MA007)
• Wireless DMX receiver card (cod. 03.LA.012)
• “C”Clamp G60 black (max. load 50Kg) (cod. 0521A004)
• “C”Clamp G60 chrome (max. load. 50Kg) (cod. 0521A004.20)
• “C”Clamp GQUICK with “Fast Lock”connection 1/4 turn (max. load. 80Kg) (cod. 0521A014)
• “C”Clamp G100 black / professional (max. load. 200Kg) (cod. 0521A015)
• Omega clamp with “Fast Lock”connection 1⁄4 turn
• Safety wire (3mm x 60 cm), ring spring catch, max. capacity load 60Kg (cod. 0521A010)
Unit Dimensions (LxWxH)
510x510x775mm
Weight: 37 Kg
Packaging Dimensions (LxWxH)
610 x 540 x 720 mm
Weight: 42 Kg
ARC 1200
7
XR2000 BEAM

DTS XR2000 BEAM Specifications

General

Brand	DTS
Model	XR2000 BEAM
Category	Lighting Equipment
Language	English
