DTS XR2000 BEAM User Manual

DMX CHANNEL 8
Parameter: COLOUR
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
000-031
Colour 1
032-063
Colour 2
064-095
Colour 3
096-127
Colour 4
128-159
Colour 5
160-191
Colour 6
192-223
Colour 7
224-255
Colour 8
DMX CHANNEL 7
Parameter: SHUTTER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
000-019
Black - out
020-039
Open
060-079
Strobe speed 1 min. (0,85 Hz)
080-089
Strobe speed 2 (1,4 Hz)
100-109
Strobe speed 3 (2 HZ)
110-119
Strobe speed 4 (3,75 Hz)
130-139
Strobe speed 5 (5 Hz)
140-149
Strobe speed 6 max. (6,75 Hz)
150-159
Pulse open speed 1 min.
160-169
Pulse open speed 2
170-179
Pulse open speed 3
180-189
Pulse open speed 4 max.
190-199
Pulse closed speed 1 min.
200-209
Pulse closed speed 2
210-219
Pulse closed speed 3
220-227
Pulse closed speed 4 max.
228-233
Colour and Gobo in black-out
234-255
Pan and Tilt in black-out
Open
040-059
Black-out
120-129
Random Strobe
090-099
ARC 1200
23
DMX CHANNEL 6
Parameter: DIMMER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-7
Black-out
8-255
Proportional dimmer
IF CHANNEL 9 = FULL COLOUR (DMX range value 0 - 63)
