DTS XR2000 BEAM User Manual

ARC 1200
XR2000 BEAM
DMX CHANNEL
14
Parameter: GOBO SHAKE
Move
DMX range Mid point
range Mode Option Function
Value DMX value
(degrees)
Gobo Shake R-L Speed 6
075-087
Gobo Shake R-L Speed 7
088-100
Gobo Shake R-L Speed 8
101-113
Gobo Shake R-L Speed 9 Max
114-126
Stop
127-138
Gobo Shake L-R Speed 1 Min
139-151
Gobo Shake L-R Speed 2
152-164
Gobo Shake L-R Speed 3
165-177
Gobo Shake L-R Speed 4
178-190
Gobo Shake L-R Speed 5
191-203
Gobo Shake L-R Speed 6
204-216
Gobo Shake L-R Speed 7
217-229
Gobo Shake L-R Speed 8
230-242
Gobo Shake L-R Speed 9 Max
243-255
DMX CHANNEL 15
Parameter: FROST
Move
DMX range Mid point
Mode Option Function
Value DMX value
range
(degrees)
000-009
No function
010-255
Linear frost position
DMX CHANNEL 16
Parameter: RESET / LAMP
Move
DMX range Mid point
range
Mode
Option
Function
Value DMX value
(degrees)
0-9
No Effect
10-60
Lamp OFF (activ.after 3 seconds)
No Effect
61-129
130-179
Lamp ON (activ.after 3 seconds)
180-200
No Effect
Internal motor reset
201-239
Total Reset
240-255
