DTS XR2000 BEAM User Manual

16 CHANNELS MODE
1 PAN msb 540°
2 PAN lsb
3 TILT msb 270°
4 TILT lsb
5 SPEED MOVEMENT
6 DIMMER
7 SHUTTER
8 COLOUR
9 CYAN
10 MAGENTA
11 YELLOW
12 GOBO
13 GOBO ROTATION/INDEX
14 GOBO SHAKE
15 FROST
16 RESET - LAMP
23 DMX PROTOCOL
DMX CHANNEL 1
Parameter: PAN msb
DMX CHANNEL 2
Parameter: PAN lsb
DMX CHANNEL 3
Parameter: TILT msb
DMX CHANNEL 4
Parameter: TILT lsb
DMX CHANNEL 5
Parameter: SPEED MOVEMENT
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0
-
10
Standard
11-25
Fast movement
26-127 Vector mode from fast to slow
128-247
Variable time reaction to
DMX signal ( fast to slow)
248-255
Silent Mode
ARC 1200
XR2000 BEAM
29
