DTS XR5 SPOT User Manual

165-175 170 Bicolour 8/9
176-186 181 Colour9
187-197 192 Bicolour 9/1
198-200 199 Right rotation speed 1 max.
201-203 200 Right rotation speed 2
204-206 205 Right rotation speed 3
207-209 208 Right rotation speed 4
210-212 211 Right rotation speed 5
213-215 214 Right rotation speed 6
216-218 217 Right rotation speed 7
219-221 220 Right rotation speed 8
222-224 223 Right rotation speed 9 min.
225-228 226 Stop
229-231 230 Left rotation speed 1 min.
232-234 233 Left rotation speed 2
235-237 236 Left rotation speed 3
238-240 239 Left rotation speed 4
241-243 242 Left rotation speed 5
244-246 245 Left rotation speed 6
247-249 248 Left rotation speed 7
250-252 251 Left rotation speed 8
253-255 254 Left rotation speed 9 max.
-
21
XR 5 SPOT
DMX CHANNEL 9
Parameter:
ROTATING GOBO WHEEL (GOBO 1)
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-25 12 Open
26-51 38 Gobo 1
52-77 64 Gobo 2
78-103 90 Gobo 3
104-129 116 Gobo 4
130-155 142 Gobo 5
156-181 168 Gobo 6
182-207 194 Gobo 7
208-213 210 Speed rotation 1 min.
214-219 216 Speed rotation 2
220-225 222 Speed rotation 3
226-231 228 Speed rotation 4
232-237 234 Speed rotation 5
238-243 240 Speed rotation 6
244-249 246 Speed rotation 7
250-255 252 Speed rotation 8 max.
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
