DTS XR5 SPOT User Manual

-
22
DMX CHANNEL 10
Parameter: GOBO 1 ROTATION/INDEX - PRISM ROTATION
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-127 Proportional index 0° / 360°
128-180 Left rotation from max to min
181-202 Stop
203-255 Right rotation from min to max
XR 5 SPOT
DMX CHANNEL 11
Parameter: FIXED GOBO WHEEL (GOBO 2)
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-16 Open
17-33 Gobo 1
34-50 Gobo 2
51-67
Gobo 3
68-84 Gobo 4
85-101 Gobo 5
102
-118 Gobo 6
119-135 Gobo 7
136-152
153-169
170-186
187-207
208-213 Speed rotation 1 min
214-219 Speed rotation 2
220-225 Speed rotation 3
226-231 Speed rotation 4
232-237 Speed rotation 5
238-243 Speed rotation 6
244-249 Speed rotation 7
250-255 Speed rotation 8 max.
Gobo 8
Gobo 9
Gobo 10
Gobo 11
DMX CHANNEL 12
Parameter: IRIS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-9
Open
10-171
Linear Iris from Open to Closed
Iris pulse at different speeds from Min to Max
172-199
200-227
228-255
Iris pulse with flash closing from Min to Max
Iris pulse with flash openig from Min to Max
