DTS XR5 SPOT User Manual

DMX CHANNEL
19
Parameter: PRISM
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
No effect
Prism inserted
-
30
DMX CHANNEL
20
Parameter: FOCUS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Linear Focus
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
DMX CHANNEL
21
Parameter:
LAMP ON/OFF - RESET
0-9
No Effect
10-60 Lamp OFF (activ.after 3 seconds)
61-129
130-179
Internal motor reset
Total Reset
180-200
201-239
240-255
No Effect
Lamp ON (activ.after 3 seconds)
No Effect
0-127
128-255
XR 5 SPOT
