DTS XR5 SPOT User Manual

DMX CHANNEL
16
Parameter: GOBO 2 SHAKE
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
Stop
0-9
10-22
23-35
36-48
Gobo Shake R-L Speed 1 Min.
Gobo Shake R-L Speed 2
Gobo Shake R-L Speed 3
49-61
62-74
75-87
88-100
101-113
114-126
127-138
139-151
Gobo Shake R-L Speed 4
Gobo Shake R-L Speed 5
Gobo Shake R-L Speed 6
Gobo Shake R-L Speed 7
Gobo Shake R-L Speed 8
Gobo Shake R-L Speed 9 Max
Stop
Gobo Shake L-R Speed 1 Min
Gobo Shake L-R Speed 2
Gobo Shake L-R Speed 3
Gobo Shake L-R Speed 4
Gobo Shake L-R Speed 5
Gobo Shake L-R Speed 6
Gobo Shake L-R Speed 7
Gobo Shake L-R Speed 8
152-164
165-177
178-190
191-203
204-216
217-229
230-242
243-255
Gobo Shake L-R Speed 9 Max
-
29
DMX CHANNEL 17
Parameter: IRIS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255
Linear Iris from Open to Closed
Iris pulse at different speeds from Min to Max
Iris pulse with flash closing from Min to Max
Iris pulse with flash opening from Min to Max
DMX CHANNEL 18
Parameter: IRIS MACROS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
No effect
0-9
10-91
92-173
174-255
XR 5 SPOT
