4- VOLTAGE AND FREQUENCY
The XR5 Spot with electromagnetic ballast can operate at 230 VOLT 50-60 Hz.
5- INSTALLATION
XR5 Spot may be either floor or ceiling mounted.
For floor mounting installations, the XR5 Spot is supplied with four rubber mounting feet under the
base.
For ceiling mounted installations, we reccomend the use of appropriate clamps to fix the unit to the
mounting surface.
The supporting structure from which the unit is hung should be capable of bearing the weight of the
unit, as should any clamps used to hang it. The structure should also be sufficiently rigid so as not to
move or shake whilst the XR5 is moving.
Four quarter turn fast locks placed on the base, allow to fix the unit in any position, by using the two fast
lock C clamps provided in the box.
5.1- Safety cable
We recommend the use of a safety cable or chain connected to the XR5 Spot and to the suspension
truss in order to avoid the fixture accidentally falling should the main fixing point fail. Make sure that the
iron cable or chain can bear the weight of the entire unit.
You may attach the safety chain to the two holes (A) located on the base of the fixture, as shown in the
picture below.
5.2- Protection against liquids
The projector contains electric and electronic components which should under no circumstances come
into contact with oil, water or any other liquid. The proper unit functioning would be compromised
should this occur.
On request 100 V (50/60 Hz) or 120 V (60 Hz).
7
A
XR 5 SPOT
