DTS XR5 SPOT User Manual

DMX CHANNEL 6
Parameter: DIMMER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
-
25
0-8 4 Black-out
9-255 Proportional dimmer
DMX CHANNEL 7
Parameter: SHUTTER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-19 Black-out
20-39 Open
60-79
Strobe speed 1 min.
80-89
Strobe speed 2
100-109 Strobe speed 3
110 -119 Strobe speed 4
130-139
Strobe speed 5
140-149
Strobe speed 6 max.
150-159
Pulse open speed 1 min.
160-169
Pulse open speed 2
170-179
Pulse open speed 3
180-189
Pulse open speed 4 max.
190-199
Pulse closed speed 1 min.
200-209
Pulse closed speed 2
210-219
Pulse closed speed 3
220-227
Pulse closed speed 4 max.
228-233
Colour and Gobo in black-out
234-255
Pan and Tilt in black-out
Open
40-59 Black-out
120-129
Random Strobe
90-99
DMX CHANNEL 8
Parameter: COLOUR
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-27
28-55
56-83
84-111
112-139
IF CHANNEL 9 = FULL COLOUR (Dmx range value 0 - 63)
140-167
168-195
224-255
196-223
Colour1 (White)
Colour3
Colour2
Colour4
Colour5
Colour6
Colour7
Colour8
Colour9
XR 5 SPOT
