DTS XR5 SPOT User Manual

21 CHANNELS MODE (DEFAULT)
1 PAN msb 540°
2 PAN lsb
3 TILT msb 270°
4 TILT lsb
5 SPEED MOVEMENT
6 DIMMER
7 SHUTTER
8 COLOUR
9 COLOUR MODE
10 ROTATING GOBO WHEEL (GOBO 1)
11 GOBO 1 MODE
12 GOBO 1 ROTATION/INDEX COARSE - PRISM ROTATION
13 GOBO 1 INDEX FINE 16 bit
14 GOBO 1 SHAKE
15 FIXED GOBO WHEEL (GOBO 2)
16 GOBO 2 SHAKE
17 IRIS
18 IRIS MACROS
19 PRISM
20 FOCUS
21 LAMP ON/OFF - RESET
-
24
DMX CHANNEL 1
Parameter: PAN msb
DMX CHANNEL 2
Parameter: PAN lsb
DMX CHANNEL 3
Parameter: TILT msb
DMX CHANNEL 4
Parameter: TILT lsb
DMX CHANNEL 5
Parameter: SPEED MOVEMENT
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-10 5 Standard
11-25 18 Fast movement
26-127 Vector mode from fast to slow
128-247 Variable time reaction to
DMX signal ( fast to slow)
248-255 251 Slow reaction time to DMX
signal
