Ducati 996SPS User Manual

23
E
Side stand (fig. 15)
Important
Before lowering the side stand, make sure that the
bearing surface is hard and flat.
Do not park on soft or pebbled ground or on asphalt melt
by the sun heat and similar or the motorcycle may fall
over.
When parking in downhill road tracts, always park the
motorcycle with its rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebars with both hands and push down on the thrust
arm (1) with your foot until it is fully extended. Tilt the
motorcycle until the side stand is resting on the ground.
Important
Do not sit on the motorcycle when it is supported
on the side stand.
To move the side stand to its rest position (horizontal
position), tilt the motorcycle to the right and, at the same
time, lift the thrust arm (1) with your foot.
Note
Check for proper operation of the stand mechanism
(two springs, one into the other) and the safety sensor (2)
at regular intervals.
1
2
Warning
The motorcycle can be started only if the side stand
is up as its safety device prevents engine start when the
stand is down.
fig. 15

Ducati 996SPS Specifications

General

Displacement	996 cc
Bore x Stroke	98 x 66 mm
Compression Ratio	11.5:1
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Seat Height	790 mm (31.1 in)
Engine Type	Liquid-cooled, 4-stroke, L-twin cylinder, DOHC, Desmodromic 4 valves per cylinder
Power	123 hp @ 9, 500 rpm
Fuel System	Electronic fuel injection, 50 mm throttle bodies
Front Suspension	Showa upside-down fork, fully adjustable
Rear Suspension	Öhlins fully adjustable monoshock
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	220 mm disc, 2-piston caliper
Dry Weight	198 kg
Fuel Capacity	17 liters
Top Speed	270 km/h (168 mph)
