Ignition - injection (fig. 46)
Make: MARELLI – I.A.W. – 1.8
Integrated system for ignition and inejction control of the
pulsed, sequential type.
System is made up of:
1) CPU
2) Power modules (one per cylinder)
3) Relays
4) Battery
5) Coils (one per cylinder)
6) Injectors (two per cylinder)
7) Air temperature sensor
8) Absolute pressure sensor
9) Pressure regulator
10) Throttle position sensor
11) Timing sensor
12) Timing idle gear
13) Flywheel
14) RPM sensor
15) Coolant temperature sensor
16) Fuel pump
17) Fuel filter
18) Key-operated switch
19) Fuse
fig. 46

Ducati 996SPS Specifications

General

Displacement	996 cc
Bore x Stroke	98 x 66 mm
Compression Ratio	11.5:1
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Seat Height	790 mm (31.1 in)
Engine Type	Liquid-cooled, 4-stroke, L-twin cylinder, DOHC, Desmodromic 4 valves per cylinder
Power	123 hp @ 9, 500 rpm
Fuel System	Electronic fuel injection, 50 mm throttle bodies
Front Suspension	Showa upside-down fork, fully adjustable
Rear Suspension	Öhlins fully adjustable monoshock
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	220 mm disc, 2-piston caliper
Dry Weight	198 kg
Fuel Capacity	17 liters
Top Speed	270 km/h (168 mph)
