43
E
Checking the coolant level (fig. 28.1)
Check the coolant level in the expansion reservoir, on the
LH side of the motorcycle.
The coolant level must be between the MAX and MIN
marks.
Top up if the level is too low.
Remove the l.h. body panel and the fuel tank. Lift the tail
guard and undo the rear screw (2, fig. 28.2). Remove the
tank from its front clamping by pulling the tank
backwards. Move it to the right leaving fuel tubing
connected.
Unscrew the filler (1, fig. 28.1) and add a mixture
consisting of water and antifreeze SHEEL Advance
Coolant or Glycoshell (35-40% of the volume) up to MAX
mark.
Refit the filler (1) and reassemble all removed parts. This
mixture improves operating conditions (coolant will start
freezing at –20°C/–4°F).
Coolant circuit capacity: 3.5 cu dm (liters) / 0.92 US Gall.
fig. 28.2
fig. 28.1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati 996SPS and is the answer not in the manual?

Ducati 996SPS Specifications

General IconGeneral
Displacement996 cc
Bore x Stroke98 x 66 mm
Compression Ratio11.5:1
Transmission6-speed
FrameTubular steel trellis frame
Front Tire120/70 ZR17
Rear Tire190/50 ZR17
Seat Height790 mm (31.1 in)
Engine TypeLiquid-cooled, 4-stroke, L-twin cylinder, DOHC, Desmodromic 4 valves per cylinder
Power123 hp @ 9, 500 rpm
Fuel SystemElectronic fuel injection, 50 mm throttle bodies
Front SuspensionShowa upside-down fork, fully adjustable
Rear SuspensionÖhlins fully adjustable monoshock
Front BrakesDual 320 mm discs, 4-piston calipers
Rear Brakes220 mm disc, 2-piston caliper
Dry Weight198 kg
Fuel Capacity17 liters
Top Speed270 km/h (168 mph)
