Ducati 996SPS User Manual

32
E
fig. 21.2
2) Press the button (1, fig. 21.2) on the throttle control.
3) Check that the stop switch (3, fig. 21.3) is positioned
to (RUN), then press the starter button (4).
Let the engine start without using the throttle control.
Important
Never operate the electric start button more than 5
seconds at a time. If needed, allow 10 seconds before
attempting to restart the engine.
4) Turn the twistgrip (2, fig. 21.2) clockwise (slow down),
the button (1) will automatically disable.
Important
Do not rev up the engine when it is cold. Allow
some time for oil to warm up and reach all points that
need lubricating.
High ambient temperature (over 35°C/95°F):
Follow the same procedure, however, do not use the
button (1).
Cold ambient temperature (below 10°C/50°F):
Follow the procedure for “Regular ambient
temperature”, however allow 5 minutes for the engine to
warm up.
3
4
fig. 21.3

Ducati 996SPS Specifications

General

Displacement	996 cc
Bore x Stroke	98 x 66 mm
Compression Ratio	11.5:1
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Seat Height	790 mm (31.1 in)
Engine Type	Liquid-cooled, 4-stroke, L-twin cylinder, DOHC, Desmodromic 4 valves per cylinder
Power	123 hp @ 9, 500 rpm
Fuel System	Electronic fuel injection, 50 mm throttle bodies
Front Suspension	Showa upside-down fork, fully adjustable
Rear Suspension	Öhlins fully adjustable monoshock
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	220 mm disc, 2-piston caliper
Dry Weight	198 kg
Fuel Capacity	17 liters
Top Speed	270 km/h (168 mph)
