Legend of fuse box (4)
Pos. Description Rat.
A-1 Main switch 30 A
B-2 Cooling electric fan 7.5 A
C-3 Left switch 3 A
D-3 High beam 15 A
E-5 Low beam 15 A
F-6 Turn indicators, warning lights, 7.5 A
tail lights and instrument panel
lights
G-7 Stop, warning horn 7.5 A
H-8 Right switch 3 A
Note
The electric system wiring diagram is at the end of
this manual.
74
