Tank filler plug
Opening
 flap (1) and  the active or passive key in the
lock. Turn the key clockwise by 1/4 of a turn to release
the lock.
 the plug (2).
Closing
Close the plug (2) with the key  and push it
down into its seat. Remove the key and close flap (1)
protecting the lock.
Note
Plug can only be closed when key is 

 refuelling, always make sure that the plug
is  in place and closed.
1
Fig 24
2
Fig 25
50
