Ducati MONSTER 695 - Torque settings; Frame torque settings

Torque settings
3 - Torque settings
Frame torque settings
Part Thread (mm) Nm tolerance ±10% Note
Chain, front sprocket
Front sprocket retaining screw M 5x0.8
6
*
LOCK 1
Front sprocket guard screw M 6x1 6
Light units
Headlight retaining screw M 8x1.25 12
Tail light nuts M 6x1 6
Screw securing headlight holder to
subframe on silent block
4
Number plate light nuts M 5x0.8 2.5
Cat's eye mounting nut M 4x0.7 2
Cable guide to headlight bracket screw M 6x1 9
Turn indicators retaining screw M 6x1 6
Headlight holder retaining screw M 6x1 10
Headlight reflector retaining screw M 4x0.7 2.3
Warning lights and indicators
Instrument panel silentblock fasteners 4
Screw retaining instrument panel to
silentblock
M 5x0.8 5
Temperature/air pressure sensor retaining screw
M 5x0.8 3
Front fork
Steering head retaining screw, center
position
M 8x1.25 23 * GREASE B
Steering head retaining screws M 8x1.25 24 * GREASE B
Bottom yoke screw M 8x1.25 20 * GREASE B -
sequence 1-2-1
Fork bottom end bolt M 8x1.25 20 * GREASE B -
sequence 1-2-1
Steering lock nut M 8x1.25 18 LOCK 2 (apply Loctite
to nut thread only)
Steering bearings ring nut M 35x1 30 * GREASE B
Front fork splashguard retaining screw M 5x0.8 5.5 LOCK 2
Electric system
Coil-to-frame retaining screw M 5x0.8 1.5
Coil-to-airbox nut M 5x0.8 3
LH and RH switch screw M 5x0.8 2.1
Key cover blind nut M 6x1 7
Key-operated switch bolt M 6x1 ** ** Shear bolt head
LOCK 2
Battery cable screw M 6x1 6
Starter motor nut M 6x1 5
Nut securing cable to contactor M 6x1 4
Speed sensor retaining screw M 6x1 10
