Using the special tool, remove head stud bolts (12).
Remove gear selector ratchet and gear stopper as described in Sect. N 7.1, Removing the gear stopper and ratchet.
Reassembling the outer components
Check O-ring (11) for wear. Change, if necessary.
Fit oil breather valve (10) with O-ring (11) inside engine block and tighten to the specified torque (Sect. C 3,
Engine
torque settings).
Tighten both plugs (14) and seals (8) to the specified torque (Sect. C 3, Engine torque settings).
Tighten oil filter cartridge support nipple (17) to the specified torque (Sect. C 3,
Engine torque settings).
Tighten the drain plug (9) with seal (28) to the specified torque (Sect. C 3, Engine torque settings) after applying the
recommended threadlocker.
