Suck the oil up from the reservoir (A).
Fill reservoir (A) with fresh oil up to MAX level.
Pump up two or three times with the lever to pressurize the circuit.
Keep the lever pulled toward the handgrip.
Loosen the bleed valve (2) so that oil flows off.
Warning
When filling up, keep oil level above MIN mark to avoid air bubbles into the circuit.
Let oil flow off from the bleed valve (2) until of different color.
Tighten the bleed valve to the specified torque (Sect. C 3,
Frame torque settings) and top up oil to correct level.
Note
Repeat the above procedure for both calipers.
