Checking engine oil level (fig. 58)
Engine oil level can be checked through the sight glass (1)
provided on the clutch cover.
Check the oil level with the motorcycle upright and the
engine cold. Allow a few minutes for the oil level to
stabilize after stopping the engine.
Oil level should be between the marks next to the sight
glass. If the level is below the bottom mark, top up with
SHELL Advance Ultra 4 engine oil.
Remove the plug (2) and top up until the oil reaches the
required level. Re-insert the plug.
Important
To replace the engine oil and filters at the intervals
specified in the maintenance table in the Warranty
Booklet, contact a Ducati dealer or authorized workshop.
Oil viscosity
SAE 10W-40
The other viscosity values shown in the table can be used
if the local average temperature is within the limits
specified for that oil viscosity.
1
2
fig. 58
–10
Unigrade
Multigrade
0 10 20 30 40 C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30
