E
75
Wire colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Notes
The system wiring diagram is at the end of this manual.
Legend for fuseboxes (1, fig. 62)
Pos. Users Val.
1-9 General 30 A
2-10 Fuel pump, injectors, coils 20 A
3-11 Key sense 10 A
4-12 Control unit power supply 3 A
5-13 Passing light 7.5 A
6-14 Parking light, instrument
panel, high/low beam
15 A
7-15 Stop light, horn 10 A
8-16 Maintainer socket 5 A
