Instrument panel (fig. 5.1 and fig. 5.2)
1) LCD, (see page 14).
2) Buttons A and B.
Buttons used to display and set instrument panel
parameters.
3) Immobilizer IMMO indicator (amber).
This light stays on steady when a wrong or unknown key
code is detected and blinks when an indication from the
immobilizer system has been reset through the override
procedure that uses the twistgrip (see page 28).
Important
The instrument panel allows the diagnosis of the
electronic injection/ignition system.
These menus are for the trained personnel only; do not
use them for any reason. Should you accidentally enter
this function, turn the key to OFF and contact an
authorised Ducati Service Centre for the necessary
inspections.
4) Revolution counter (rpm).
Shows the engine rotation speed/minute.
km/h
miles
mph
km/L
mpgal
3
4
2
1
fig. 5.1
