Ducati ST3 - Page 177

E
68
Instrument panel covers
Undo the two screws (1) securing the rear plate (2) to the
headlight fairing.
Pull out the rear plate (2) from the front plate (3).
Undo the screws (4) and remove the windscreen (5) to
remove the front plate (3).
Undo the screws (6), disconnect the wiring from the
instrument panel and remove the front plate (3) complete
with instrument panel.
4
4
5
fig. 59
fig. 60
6
6
7
6
fig. 61
