E
107
ST3S ABS
Legend to fuse box
Pos. El. item Rat.
1-9 Key-on 10 A
2-10 Parking lights, high /low
beam
15 A
3-11 Turn indicators, horn, stop 20 A
4-12 Instrument panel 5 A
5-13 Heated handgrips 5 A
6-14 ECU power supply 3 A
7-15 Key-on ECU ABS 10 A
8-16 Fan 7.5 A
a Power outlet 20 A
b Injection 20 A
c ABS power supply 30 A
