24
4.1 Hook lubrication (only for subclasses with oil lubrication of the hook)
To lubricate the hook use only DA 10 lubricating oil or an equivalent oil of the
following specification:
- Special lubricating oil DA 10 / colourless / resistant to light and ageing
resistant / high wear and corrosion protection
- Viscosity / 40°C: 10 mm²/s - ISO VG10
DA 10 is available from DÜRKOPP ADLER retail outlets under the following
part numbers
250 ml container: 9047 000011
1-litre container: 9047 000012
2-litre container: 9047 000013
5-litre container: 9047 000014
Caution: Danger of injury!
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
.
Maintenance work to be
carried out
Explanation
Operating
hours
Lubrication of the
hook
The oil level shall not fall below the "MIN" level of the oil
reservoir 1.
Top up the oil through the bore hole 2 up to the marking line
"MAX"
8
