6.5 Thread clamp
The sewing machine is equipped with thread clamp as standard.
Table of all parameters relating to the function "thread clamp" at seam
beginning.
Note: If the parameter 235 is set to "3" or "4", the holding power for sewing foot lifting during
thread clamping can be adjusted via parameter 239 :
The value of parameter 239 must be set to:
- a lower value, if the holding power for sewing foot lifting is too strong or
- a higher value, if the holding power for sewing foot lifting is too weak
(for example: thread breakage at seam beginning).
Parameter Number Designation Preset value
without Thread clamp function ON/OFF
Switch the thread clamp function using the F-key at the operating panel
C-200 ON/OFF.
(Function "F1" for the thread clamp function must be adjusted)
F1 to ON
234 Seam end with the thread trimming stitch forward or backward with
thread wiper function at the seam end
or
Thread clamp at seam beginning
0 = Trimming stitch forward with thread wiper function
1 = Trimming stitch backward with thread wiper function
2 = Trimming stitch forward with thread clamp function
3 = Trimming stitch backward with thread clamp function
2
235 Function thread clamp (NFL = sewing foot lifting)
0 = Thread clamp off
1 = Thread clamp without NFL with parameter 210 + 211
2 = Thread clamp without NFL (for light material)
(FK ON = 108°; FK OFF = 268°)
3 = Thread clamp with NFL (for heavy material)
(FK ON = 108°; FK OFF = 268° / NFL ON = 108°, NFL OFF = 154°)
4 = Thread clamp with NFL (for applications with high sewing foot pres-
sure or thread breakage at seam begin)
(FK ON = 108°; FK OFF = 268° / NFL ON = 44°, NFL OFF = 154°)
5-11 = Function thread clamp not suitable for class 281
2
239 Holding power for sewing foot lifting (NFL) during thread clamping
(Effective if parameter 235 is set to "3" or "4")
1% - weak holding power
100% - strong holding power
25
155 Output function for PIN 27 (OB)
FK = Thread clamp (additionally check parameter 234 and 235)
FK
210 Thread clamp ON in angular degree
Set parameter 235 to "1" or "5"
0°
211 Thread clamp OFF in angular degree
Set parameter 235 to "1" or "5"
0°
