2.5 Technical Data
Noise: Workplace-related emission value in accordance with DIN 45635-48-A-1-KL2
281-140342 LC = _dB (A)
Stitch length: _ mm Sewing foot stroke: __ mm Speed: ____ min
-1
2.6 Technical Data Subclasses
Subclasses
281-140342-01
Type of stitch Lockstitch 301
Hook type Horizontal hook
lubricated
Number of needles 1
Needle system 134 / 797 / Dxp1
Dimension of the needle bar piston [mm] 2.0/ 1.62
Needle size [Nm] 65 - 120
Max. sewing thread [Nm] 30 / 3
Stitch length forward/ backward [mm] 4.5
Max. Speed [min
-1
]
5,000
Speed at delivery [min
-1
]
4,800
Sewing foot stroke max when lifted with the knee lever [mm] 14.5
Sewing foot stroke max when lifted with the solenoid [mm] 12
Sewing foot stroke at delivery [mm] 9
Weight [kg] 42
Rated voltage [V/Hz] 200 - 240V
50/60Hz
Rated voltage at delivery [V/Hz] 1 x 230V
50/60Hz
Rated output [kVA] 0.5
Dimension of package including machine head, kit, drive L =785, H = 694, B = 300 mm
Gross weight [kg] 54.5
