403-618-03 Infinity™ Series Servo Ultrasonic Press Systems User Manual
15
SECTION 3 | INSTALLATION
Figure 3-6
MOUNTING HOLE
LOCATIONS

Figure 3-7
UNITS: INCHES [MM]
n.50 [12.7]2X
18.6 [472]
ULTRASOUND STACK
CENTER
24.84 [630.9]
13.22 [335.8]
.70 [17.8]
8.05 [204.3]
MOUNTING HOLE
LOCATIONS
