Duke SUB-CP-TC Series User Manual

7
Installation and Operation of: Tri-Channel Cold Pan
Overall
Width
“X”
Overall
Height
Overall
Depth
TRI-Channel Top
Cutout Dimensions
Liner Depth
Cubic
Ft.
Crated
Weight
Width Depth
Pans
in cm in cm in cm in cm in cm in cm lbs kg
RS021637 48 121.92 35.75 90.80 34.25 87 43 109.22 21.375 54.29 21.3 54.10 9 - 1/3 size 71 310 140.61
RS020498 60 152.40 35.75 90.80 34.25 87 55.8 141.73 21.375 54.29 21.3 54.10 12 - 1/3 size 87 420 190.51
RS021652 74 187.96 35.75 90.80 34.25 87 68.6 174.24 21.375 54.29 21.3 54.10 15 - 1/3 size 108 548 248.57
RS021496 86 218.44 35.75 90.80 34.25 87 81.4 206.75 21.375 54.29 21.3 54.10 18 - 1/3 size 127 636 288.48
RS040921 48 121.92 35.75 90.80 34.25 87 43 109.22 21.375 54.29 21.3 54.10 9 - 1/3 size 71 310 140.61
RS040923 60 152.40 35.75 90.80 34.25 87 55.8 141.73 21.375 54.29 21.3 54.10 12 - 1/3 size 87 420 190.51
RS041819 74 187.96 35.75 90.80 34.25 87 68.6 174.24 21.375 54.29 21.3 54.10 15 - 1/3 size 108 548 248.57
RS041821 86 218.44 35.75 90.80 34.25 87 81.4 206.75 21.375 54.29 21.3 54.10 18 - 1/3 size 127 636 288.48
RS021641 48 121.92 35.75 90.80 34.25 87 43 109.22 21.375 54.29 21.3 54.10 9 - 1/3 size 71 310 140.61
RS021500 60 152.40 35.75 90.80 34.25 87 55.8 141.73 21.375 54.29 21.3 54.10 12 - 1/3 size 87 420 190.51
RS021655 74 187.96 35.75 90.80 34.25 87 68.6 174.24 21.375 54.29 21.3 54.10 15 - 1/3 size 108 548 248.57
RS021638 86 218.44 35.75 90.80 34.25 87 81.4 206.75 21.375 54.29 21.3 54.10 18 - 1/3 size 127 636 288.48
DIMENSIONS:
Model #SUB-CP-TCXX M - (XX will be replaced with size of units (ie. Model# for 48” TRI-Channel would be SUB-CP-TC48 M)
SPECIFICATIONS  continued
Electrical and Refrigerant:
Model Section
Refrigerant - R-404A
Amount ozs. / grms.
Volts
"Frequency
(Hz)"
Amps
"Watts
(Label)"
SUB-CP-TC36 2 13 / 369 115 60 7.9 910
SUB-CP-TC36 2 13 / 369 220 60 3.3 730
SUB-CP-TC36 2 13 / 369 230 50 3 690
SUB-CP-TC48 3 14 / 397 115 60 7.9 910
SUB-CP-TC48 3 14 / 397 220 60 3.3 730
SUB-CP-TC48 3 14 / 397 230 50 3 690
SUB-CP-TC60 4 15 / 425 115 60 7.9 910
SUB-CP-TC60 4 15 / 425 220 60 3.3 730
SUB-CP-TC60 4 15 / 425 230 50 3 690
SUB-CP-TC74 5 16 / 454 115 60 8.45 970
SUB-CP-TC74 5 16 / 454 220 60 4.8 1060
SUB-CP-TC74 5 16 / 454 230 50 4.8 1100
SUB-CP-TC86 6 16 / 454 115 60 8.45 970
SUB-CP-TC86 6 16 / 454 220 60 4.8 1060
SUB-CP-TC86 6 16 / 454 230 50 4.7 1080
