Duplex 340 - 1.7 Loading the Washing Liquid; Starting up

DUPLEX 340-420-620
16
1
Heavy duty wash for very dirty floors.
2
Delicate wash for all types of floors.
3
Normal carpets and wooden floors.
4
Long-pile carpets.
5
Transporting position.
(REST TRASLATION)
1.8 STARTING UP
1. Make sure that the handle is in the Rest
position (perfectly vertical) and that the
slide switch is in the “Translation”
position (REST TRANSLATION);
2. Plug the mains cable into an earthed socket.
MU RT
3. Shift the slide switch to one of the four
available positions according to the type
of cleaning you wish to perform (figure
“1.11”).
(MU= Mop-Up)
Figure 1.10
1
2
3
4
5
Figure 1.11
WARNING
During machine operation it is recommended to keep the cable
well clear of the brushes to prevent it from being
damaged.
